    China Positive PS Plate for Offset Printing (Available Custom Sizes)

    PS plate (Presensitized Plate) is a popular name in the printing industry. The full name is pre-coated photosensitive lithography. The PS plate is a plate material for offset (lithographic) printing that is coated with a layer of photosensitive resin on the electrolytically roughened and anodized aluminum plate base. The photosensitive plate base uses 0.27mm and 0.14mm aluminum plates.

    Click here to know more about What is PS Plate>>



    Our Strength

    Henan Huida Print-All Technology Co., Ltd. found in 2003, with almost 20 years of development, has become the largest offset plate manufacturer in China.
    Main products including digital photosensitive plates and conventional plates:
    1. Positive Conventional PS Plate
    2. Positive Thermal CTP Plate
    3. Positive CTCP Plate
    4. Double Layer Thermal CTP Plate

    which are widely used in the printing industry, like newspaper printing, cans printing, electronic printing, etc.



    Get a Quote

    Send your message to us by the below button (SEND INQUIRY):

    For better quotations, include:

    - A self-introduction

    - Special requests, if any

    We will reply to you within 24 hours!!!

    Product Type

    Positive Conventional PS Plate

    Color

    Blue

    Aluminum

    Aluminum alloy 1050/1060 standard

    Plate Thickness

    0.15/0.20/0.25/0.30/0.40mm

    Maximum Coil Width

    1350mm

    Spectral Sensitivity

    320~450nm

    Exposure Energy

    30 seconds with 3KW iodine-gallium lamp, distance: 1 meter

    Developing Condition:

    22-26℃, 25-35S

    Safe-light

    Under Yellow Light

    Resolution

    2-98% at 200lpi

    Run Length

    100,000 copies(Unbaked), 200,000 copies(Baked)

    *Run-Length varies with its printing conditions and imaging content, including paper,ink

    Shelf Life

    18 Months

    Storage Conditions

    Temperature  10-25℃, 40%-60% humidity

    Keep away from sunlight and humidity. Pack height≤1.5 meters
